DC12V Individually digital full color 30led 5050 RGB LED Strip sk6813 (good replacement of ws2815)

one pixel falled , donot affect next pixel leds workling ,good replacment of ws2815.

Ip68 sk6813 pixel led strip 12v with 60led per meter

Key specification

Fastest pixel rgb LED Strip
Led type:5050 SMD LED
IC type: sk6813
PCB Width:10mm
Led lighting angle: 120°
LED Qty: 30leds/m, 30led/m

IP Rating IP20, IP65, IP67, IP68.

Single-flow, gradient, chase, scan and other full-color effects;
Splicing to achieve text movement and video animation and other dynamic effects;
Can be bend and cut, can achieve a certain curvature and length of the modeling screen;
1 LED 1 IC, individual controlled, can be made into high-density high-definition display;

Advantages

sk6813 led strip with dual signal ,one pixels no work , no affect the next one working
sk6813 led with capacitance inside the led lamp
one roll(10meters)can be powered with one power input without color difference,
Pure copper bracket and 99.99% gold wire for sk6813 LED
2OZ FPCB(35um cooper)with double cooper layer2 sides membrane cover the PFCB.Make sure the copper no drop from the pcb board ,
White PCB and black PCB optiona
It comes in 1 meters per reel with 4Pin female/male JST SM connector on both end and separated Power / Ground Wires . Customized length is workable .
Flexible PCB material . ever 1LEDcan be cut , there is cut lines every 16.6mm for 60leds/M
256 Gray scale(8bits)

Controller system:

1.Offline controllers, online controller work with computer,Such as LEDedit,ledstudio,ect

2.DMX console ,

3.Art net led controller ,support Madrix software & map and any other artnet software.

4.Also the singlechip,such as the Arduino.

Waterproof Type

IP20 non waterproof:3M sticker on the back, easy installation.
IP65 waterproof: Silcone gel or epoxy on the surface,3M sticker on the back.
IP67 waterproof: Silicone tube, equipped with card buckle and screw.
IP68 waterproof: Silicone gel or epoxy inside silicone tube,equipped with card buckle and screw.

Applications:

Widely used for decoration use, hotels, clubs, shopping malls,night bar, disco
Architectural decorative lighting, boutique atmosphere lighting
Extensively applied in Backlighting, concealed lighting, channel letter lighting
Emergency & security lighting, advertisement sign lighting
Decorative lights for holiday, event, show exhibition
Applicable for automobile and bicycle decoration, border or contour lighting

download th datasheet here please
