rainproof Dc5V Dc12V Dc24V 400watt led power supply for project use with ce and Rohs approved
Input Voltage: AC 110-240V
Output Voltage: DC12V 24V Power: 400W
Output Voltage: DC5V Power: 350W
Shell Material: Metal case / Aluminum case
Working Temperature: 0~40C
Storage Temperature: -20~60C
Ambient Humidity: 0~95% Non-Condensation
Features:
High power effective, reliability with industry standards
Built-in over voltage, over current, and short circuit protection
The size is for reference only : the actual one shall prevail
DC12V 400W: 19x12x5.5cm(7.5x4.4x2.2in)
DC24V 400W:188*123*58mm
Package:
45pcs per cartoon cartoon size: 59cmX28cmX37.5cm volume weight :12.5kg Gross weight: 23kg
电源为什么要使用80%的功率
①电源自启动本身会有功率损耗。
②布线接户外灯具会有线损，通常1米/1w。
③长时间带载，温度升高产生功率损耗。
④留出20%旷量使用，能让电源更稳定，使用寿命更长。
Why the power supply use 80% of the total power?①The self-starting of the power supply will cause power loss.②There will be wire loss when wiring connected to lamps, usually 1m/1w.③ Long-term load, the temperature rises, resulting in power loss.④ Set aside 20% of the open capacity for use, which can make the power
There is other power optional !
